Application:

•  Clean water disinfection: Water, secondary water supply, drinking water, pure water, aquaculture, food and fish processing water sterilization; electronic ultra-pure water sterilization and addition of organic carbon

•  Recycled water disinfection: Swimming pool water, landscape waters, industrial circulating cooling water

•  Wastewater Disinfection: Municipal wastewater, water reuse, hospital sewage, slaughterhouse waste, oil field injection water.

Features:

• System design using U.S.NSF55,and under standard of CJ/T204-2000

• Import high-strength loe-pressure UVlamps,life of 9000-13000hours.

• Compelte pruduct specifications,flow range from 0.1-500T/Hr.

• 304/316L stainless steel  made the pipeline, automatic welding.

• Supporting high effciency electronic ballast,device sterilization rate attain 99.99%



Specification:

• Model	Water flow	Power	Size:mm	Water Input & Ouput Size	Max Pressure
  SH-UV-3T	3T/T	40W×1	950*125*250	1″	0.8Mpa
  SH-UV-6T	6T/H	40W×2	950*138*280	1.5″	0.8Mpa
  SH-UV-8T	8T/H	40W×3	950*170*310	2″	0.8Mpa
  SH-UV-10T	10T/H	40W×4	950*170*310	2″	0.8Mpa
  SH-UV-12T	12T/H	40W×4	950*195*335	2″	0.8Mpa
  SH-UV-15T	15T/H	40W×5	950*195*335	2″	0.8Mpa
  SH-UV-20T	20T/H	80W×3	950*205*405	2.5″	0.8Mpa
  SH-UV-25T	25T/H	80W×4	950*275*465	2.5″	0.8Mpa
  SH-UV-30T	30T/H	120W×3	1250*275*545	3″	0.8Mpa
  SH-UV-40T	40T/H	120W×4	1250*275*550	3″	0.8Mpa
  SH-UV-50T	50T/H	120W×5	1250*275*550	4″	0.8Mpa
